SUNSYNK 5.12KW BATTERY 51.2V
Original price was: R18,900.00.R17,600.00Current price is: R17,600.00.
SUNSYNK 5.12KW BATTERY 51.2V
Sunsynk 5.12kW battery 51.2V is a lithium-ion battery It provides a reliable backup power supply for supermarkets, banks, schools, farms and small factories to smooth the load curve and achieve peak load transfer. It can also improve the stability of renewable systems and promote the application of renewable energy.
It is characterized by high integration, good reliability, long service life, wide working temperature range, etc. The battery energy storage system is modular. Each battery module has a capacity of 100AH .. Its total energy can be expanded from 4.61kWh to 5.12 kWh.
The series is especially suitable for applications of high power, limited installation space, restricted load-bearing and long-life cycle. The battery has a built-in management system, which can manage and monitor cell information, including voltage, current and temperature. What’s more, BMS can balance cell charging and discharging to extend cycle life.
| Battery Chemistry | LiFePO4 | |
| Capacity (Ah) | 100 | |
| Scalability | Max 32 pcs in parallel (163.8kWh) | |
| Nominal Voltage | 51.2 | |
| Operating Voltage | 43.2 – 57.6 | |
| Energy (kWh) | 5.12 | |
| Usable Energy (kWh) | 4.61 | |
| Charge / Discharge Current (A) | Recommend [2] Max [2] Peak [2 mins, 25°C] | 50 100 150 |
| Recommend Depth of Discharge | 90% | |
| Dimension (w/h/d) mm | 440 x 640 x 140 | |
| Weight Approximate (kg) | 50 | |
| Master LED Indicator | 5 LED (20%-100%) 3 LED (working, alarming, protecting) |
|
| IP Rating of Enclosure | IP65 | |
| Working Temperature | Charge: 0°C – 55°C Discharge: -20°C – 55°C |
|
| Storage Temperature | 0°C – 35°C | |
| Humidity | 5% – 95% | |
| Altitude | ?2000m | |
| Cycle Life | ?6000 (25±2°C, 0.5C, 70%EOL) | |
| Installation | Wall Mounted or 19-inch standard cabinet | |
| Communication Port | CAN2.0, RS485 | |
| Warranty Period [3] | 5 years | |
